Taller reefs key to oyster restoration

  • Large oyster
    Large oyster  Conventional wisdom states that native oysters almost always die before they reach the minimum size for the fishery, 76 mm in shell length. Here is live, large oyster over 100-mm shell length from a restored reef. Currently, many millions of oysters larger than 76 mm are thriving are thriving at high densities on the restored reefs.  Photo courtesy of VIMS
  • Taller Reef
    Taller Reef  Underwater photograph representing the average conditions of taller, high-relief reefs.  Photo courtesy of VIMS
  • Shorter  Reefs
    Shorter Reefs  Underwater photograph representing average conditions of shorter, low-relief oyster reefs.  Photo courtesy of VIMS
  • High-Relief Reef
    High-Relief Reef  A typical high-relief reef sample, filled with live oysters. These reefs are thriving.  Photo courtesy of VIMS
  • Low-Relief Sample
    Low-Relief Sample  A characteristic low-relief sample indicative of a restoration reef that is degrading and will eventually revert to an unrestored bottom state. No live oysters are present and the thin shell layer has a coating of sediment.  Photo courtesy of VIMS
  • Recruitment
    Recruitment  Image of the remarkable recruitment that occurred on private oyster leases in the Great Wicomico River in fall of 2008. Such high recruitment has not been seen in this region in many years, and it is most likely due to the 185 million oysters living at very high densities on the restored oyster reefs. In 2009, local leaseholders have indicated that oyster production on many of their private leases has been the highest in decades.  Photo courtesy of VIMS
  • Mussels
    Mussels  A cluster of oysters from a high-relief reef where the oysters have grown together into a cohesive unit. O f interest is the mussel nestled into the cluster in the lower left corner and a young-of-the-year oyster visible on the bottom right corner. Mussels occurred commonly in crevices within oyster clusters, and thereby provide additional ecological benefits to the restored reef system. Mussels rarely settled on low-relief reefs, which had few clusters of oysters and consisted of mostly single oysters attached to individual shells.  Photo courtesy of VIMS
Photo - of -

A five-year study of oyster-restoration techniques in Chesapeake Bay shows that taller reefs in an extensive network of large sanctuaries is critical for re-establishing self-sustaining populations of native oysters.

The study, to appear in the July 30th issue of Science Express, was conducted by Virginia Institute of Marine Science graduate students David Schulte, Russ Burke, and professor Rom Lipcius. They compared oyster abundance and growth on reefs built to stand 10-18 inches above the seafloor with reefs that rise only 3-5 inches. The research has grabbed the attention of national media outlets, including the New York Times and the Washington Post.

The US Army Corps of Engineers constructed the reefs in 2004 by placing old oyster shells in 9 discrete sets of reefs covering more than 90 acres in the Great Wicomico River, a small Chesapeake Bay tributary that lies between the Rappahannock and Potomac rivers and is known for having much higher recruitment than other areas in the Bay. Harvesting of oysters on these sanctuary reefs is permanently prohibited.

Sampling by the VIMS team in 2007 using oyster patent tongs and underwater video showed that the taller Wicomico reefs had four times as many oysters as the shorter reefs, and that the oysters on the taller reefs were bigger and faster-growing than those growing closer to the bottom. All the oysters grew from larvae released by nearby wild oysters.

The taller reef areas held the highest densities of oysters ever recorded on a restored oyster reef in the Bay, more than 1,000 oysters per square meter, compared to 250 oysters per square meter on the shorter reefs. Pre-restoration surveys of the study area recorded fewer than 2 oysters per square meter. Chesapeake Bay reefs that are open to harvest typically hold from 2-11 oysters per square meter.

The Great Wicomico's re-established population, which the researchers estimate at 184.5 million oysters, is the largest of any native oyster population worldwide. The restored population, which exists on 86.5 acres of reefs, is roughly equivalent to the entire oyster population on all of Maryland's 270,000 acres of public oyster grounds. The authors calculate that it is 57-times larger than the pre-restoration population; far exceeding the Chesapeake Bay Program's previously unachieved restoration goal of a 10-fold increase of the 1994 baseline by 2010.

The authors say the taller reefs are successful because they expose their oysters to stronger currents, which sweep away sediments that can otherwise clog the delicate filters that oysters use to feed. The currents also provide a steady stream of food, which promotes rapid growth and helps the oysters better resist the diseases that purportedly kill most Bay oysters before they reach their second year, though evidence is mounting that oysters can develop disease resistance if provided with adequate reef structure.

The higher quality reefs also attract higher numbers of oyster recruits, increasing the chances they will be self-sustaining over a long period of time.

"Adding several inches to the height of a reconstructed reef provides a 'jumpstart' that allows the oysters to grow, reproduce, and begin to form a self-sustaining reef community," says Schulte.

Importantly, the taller reefs appear to be growing fast enough to outpace chemical dissolution, breakdown by other organisms, and burial by the turbid Chesapeake's abundant sediments. According to the authors, these forces have short-circuited previous efforts to restore oysters in Chesapeake Bay and elsewhere, by precluding the growth of the vertical, cohesive framework that forms the foundation of a healthy oyster reef.

They also credit the reefs' continuing upward growth to the absence of fishing pressure notably tonging and power dredging. In addition to removing the uppermost layer of living oysters, these methods destroy the underlying shell layers that comprise the reef framework.

Lipcius says "Our results suggest that oyster reefs exist in two alternative states, one a heavily-sedimented, degraded state and the other a vertically-accreting, elevated reef with abundant oysters, which provides a positive feedback to reef integrity."

 The taller reefs of the Great Wicomico have persisted and, more importantly, thrived for nearly five years, says Schulte, well past the typical longevity of failed oyster reefs. "These 'high-relief' reefs are gaining shell material and establishing oyster densities at rates previously unrecorded on native oyster restoration projects."

He adds that the vertical growth and cohesiveness of the taller Wicomico reefs show that they are "coalescing into the historic, natural oyster-reef architecture typical of pre-exploitation reefs."

Exploitation through harvesting of meat and shells has devastated native oyster populations around the world, including those in North America, Europe, and Australia. Chesapeake Bay's oyster population currently stands at less than 1% of its historical abundance.

"Although disease will kill some oysters in the Great Wicomico, the recent development of disease tolerance in oysters on sanctuary reefs of lower Chesapeake Bay bodes well for the long-term persistence of this population and the ecosystem benefits it provides," adds Schulte.

Preliminary results from the team's survey of the reefs in winter 2009 show that the high-relief reefs continue to develop and harbor more than 1,000 oysters per square meter, most of which are adults. Further, recruitment in the Great Wicomico River appears to have been enhanced, as evident on hard-bottom habitats throughout the system. Consequently, these reefs, which are now 5 years old, are not degrading and are developing into the robust reefs of centuries past.The authors contend that the study "validates ecological restoration of native oyster species," and that "similar approaches with other natural and artificial reefs could lead to recovery of the native oyster throughout North America, as well as other ecosystems worldwide."
